The innovative solution for the delivery of the manufactured unit directly to the place of use.
InOutIn is the innovative solution for the transport of goods, designed to deliver the unit produced to the place of use. A patented electro-hydraulic handling system is the core of the system: the containers are equipped with a hydraulic lifting system for autonomous lowering, which allows the goods to be brought to the ground level in total safety, facilitating loading and unloading in total autonomy.
The product is fixed, directly from the assembly line to the electro-hydraulic handling system, allowing the unit to be moved easilly.
The containers are equipped with a hydraulic lifting system for autonomous lowering.
WARNING! For the correct positioning of the container the manoeuvring space for trucks must be at least 18 linear meters, 25 for road trains.
WARNING! For the correct positioning of the container the manoeuvring space for trucks must be at least 18 linear meters, 25 for road trains.
WARNING! The height of the ramp for trucks must be a maximum of 1.2 meters.
Is loading/unloading access restricted? WARNING! For proper unloading, the minimum passage for trucks is 4.2 meters x 2.7 meters. BEWARE of ledges, steps, etc.
Direct arrival at the factory and relative unloading of goods.
BEWARE of the flooring. The pressure points are very high (e.g. tiles, asphalt, etc.)
BEWARE of the paths inside your plant
WARNING! The slope of the ramp must not exceed 5%.
BEWARE of the unevenness of the passable steps, maximum 10 cm.
BEWARE of the internal passages, areas and compartments!
